Name: Survey Monuments

Display Field: MONUMENTID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description:

Copyright Text:

Default Visibility: true

MaxRecordCount: 2500

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1411867.8690375797
YMin: 1332120.7218462378
XMax: 1702366.9501117468
YMax: 1555155.0461179093
Spatial Reference: 2903  (2903)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: MONUMENT_TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Horizontal
  Label: Horizontal
  Description: N/A
  Symbol:

• Value: Vertical
  Label: Vertical
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [0, 0, 0, 255]
  Size: 10.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [255, 255, 255, 255] Width: 1
• Value: Vertical and Horizontal
  Label: Vertical and Horizontal
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• MONUMENTID ( type: esriFieldTypeString, alias: MONUMENTID, length: 32 )
• MONUMENTSTATUS ( type: esriFieldTypeString, alias: MONUMENTSTATUS, length: 11 )
• ZONE ( type: esriFieldTypeString, alias: ZONE, length: 8 )
• DateMadeActive ( type: esriFieldTypeDate, alias: DateMadeActive, length: 8 )
• DateMadeInActive ( type: esriFieldTypeDate, alias: DateMadeInActive, length: 8 )
• NAD83LAT_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83LAT_DEG )
• NAD83LAT_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83LAT_MIN )
• NAD83LAT_SEC ( type: esriFieldTypeDouble, alias: NAD83LAT_SEC )
• NAD83LON_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83LON_DEG )
• NAD83LON_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83LON_MIN )
• NAD83LON_SEC ( type: esriFieldTypeDouble, alias: NAD83LON_SEC )
• ELIPHEIGHTMTR ( type: esriFieldTypeDouble, alias: ELIPHEIGHTMTR )
• NAD83ORDER ( type: esriFieldTypeSmallInteger, alias: NAD83ORDER )
• NAD83CLASS ( type: esriFieldTypeSmallInteger, alias: NAD83CLASS )
• NAD83_NORTH_USFT ( type: esriFieldTypeDouble, alias: NAD83_NORTH_USFT )
• NAD83_EAST_USFT ( type: esriFieldTypeDouble, alias: NAD83_EAST_USFT )
• NAD83_NORTH_MTR ( type: esriFieldTypeDouble, alias: NAD83_NORTH_MTR )
• NAD83_EAST_MTR ( type: esriFieldTypeDouble, alias: NAD83_EAST_MTR )
• GRNDTOGRIDFACTOR ( type: esriFieldTypeDouble, alias: GRNDTOGRIDFACTOR )
• MAPPINGANGLE ( type: esriFieldTypeString, alias: MAPPINGANGLE, length: 11 )
• GRS80GEOIDSEPMTR ( type: esriFieldTypeDouble, alias: GRS80GEOIDSEPMTR )
• NAD83SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAD83SOURCEDATAFILE, length: 255 )
• NAD83DATELOADED ( type: esriFieldTypeDate, alias: NAD83DATELOADED, length: 8 )
• NAVD88ORTHOHGHT_USFT ( type: esriFieldTypeDouble, alias: NAVD88ORTHOHGHT_USFT )
• NAVD88ORDER ( type: esriFieldTypeSmallInteger, alias: NAVD88ORDER , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...6 more... )
• NAVD88CLASS ( type: esriFieldTypeSmallInteger, alias: NAVD88CLASS , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...1 more... )
• NAVD88SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAVD88SOURCEDATAFILE, length: 255 )
• NAVD88DATELOADED ( type: esriFieldTypeDate, alias: NAVD88DATELOADED, length: 8 )
• FILELINKDRIVE ( type: esriFieldTypeString, alias: FILELINKDRIVE, length: 255 )
• FILELINKOBSTRUCTDIAG ( type: esriFieldTypeString, alias: FILELINKOBSTRUCTDIAG, length: 255 )
• FILELINKDRAWINGFILE ( type: esriFieldTypeString, alias: FILELINKDRAWINGFILE, length: 255 )
• Note ( type: esriFieldTypeString, alias: Note, length: 255 )
• DATASHEETLINK ( type: esriFieldTypeString, alias: DATASHEETLINK, length: 255 )
• MONUMENT_TYPE ( type: esriFieldTypeString, alias: MONUMENT_TYPE, length: 50 , Coded Values: [Vertical: Vertical] , [Horizontal: Horizontal] , [Vertical and Horizontal: Vertical and Horizontal] )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Description_from_Export ( type: esriFieldTypeString, alias: Description_from_Export, length: 1073741822 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 500 )
• Technician_last_checked ( type: esriFieldTypeString, alias: Technician_last_checked, length: 255 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GRND_TO_GRID_FACTOR ( type: esriFieldTypeDouble, alias: Ground to Grid Factor )

Supported Operations:   Query   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
